Stainless steel sprocket maintenance method

Whether the function of the 06B 08B 10B 12B 16B Stainless steel Sprocket can persist for a long time has a great connection with the maintenance of the later period. The maintenance of the sprocket should include various parts of the machine, so that the service life extension of the machine equipment is extended, and the maintenance of the stainless steel sprocket is particularly important.

Stainless steel sprocket should always insist on cleaning and stick to the function of stainless steel sprocket. It is not rainy or wet. When using the bicycle, pay attention to cleaning the stainless steel sprocket and chain. The stainless steel sprocket is not afraid of snow and water under normal conditions. However, the snow and the dust and impurities, especially the mud, are often trapped in the stainless steel sprocket, which speeds up the wear of the stainless steel sprocket, which can be broken or the cone can be loosened for a long time.

Stainless steel sprocket should be cleaned with clean cloth. Do not touch the water, but the cloth can not be cleaned in one place. It is also required to stop the cleaning of the whole brush. The brush can stop cleaning some dead spots without cleaning and cleaning. The overall cleaning degree of the stainless steel sprocket.

06B 08B 10B 12B 16B Stainless steel Sprocket maintenance:

1, the sprocket's tightness should be suitable, too tight will increase the power consumption, the bearing is easy to wear; too loose sprocket is easy to jump and unchain. The sprocket's elastic level is: lifted or pressed from the middle of the sprocket, about 2% to 3% of the center distance of the two sprocket wheels.

2. The sprocket should be mounted on the shaft without swinging and tilting. In the same transmission assembly, the end faces of the two sprockets should be in the same plane. When the center distance of the sprocket is less than 0.5 m, it can be biased to 1 mm; when the center distance of the sprocket is more than 0.5 m, it can be biased to 2 mm. However, there is no possibility of rubbing the sprocket side of the sprocket. If the two wheels are too large, the chain is prone to de-chaining and accelerated wear. Care must be taken to check and adjust the offset when changing the sprocket.

3. After the sprocket wears seriously, the new sprocket and the new sprocket should be changed at the same time to ensure good meshing. It is not possible to change only a new sprocket or a new sprocket separately. Otherwise, the meshing may not be accelerated to accelerate the wear of the new sprocket or the new sprocket. After the sprocket tooth surface wears to a certain level, it should be turned over in time (refer to the sprocket used for the adjustable surface) to extend the operation time.

4, the new sprocket is too long or stretched after use, it is difficult to adjust, you can see the situation to remove the link, but must be even. The link should pass through the reverse side of the sprocket, the locking piece is inserted outside, and the opening of the locking piece should be in the opposite direction of rotation.

5, the sprocket should be filled with smooth oil in time. Smooth oil must enter the fit clearance between the roller and the inner sleeve to improve working conditions and reduce wear.

6, the old sprocket can not be mixed with the local new sprocket, otherwise it is easy to produce impact in the transmission, pull the sprocket.

7. When the machine is stored for a long time, the 06B 08B 10B 12B 16B Stainless steel Sprocket should be removed and cleaned with kerosene or diesel oil, and then coated with oil or butter in the boring center.
