ANSI 35B-3 50T Triplex Chain Sprocket

Product Item:HXPT-062

Model: ANSI 35A-B-1-2-3 Sprockets and Platewheel

Material: C45, stainless steel, etc.

Surface treatment:Teeth hardened, Black oxide, Zinc plated, Electrophoresis etc

Package:Standard export case, individual package (neutral or colorbox) available.

ANSI 35-3 Hub Steel Sprocket

For #35 Triple Strand Chain with

3/8 Inch Pitch

3/16 Inch Roller Width

0.200 Inch Roller Diameter

0.169 Inch Single Tooth Width (B1)

0.960 Inch Sprocket Tooth Face Width (B3)

6.154 Inch Outside Diameter (Approximate) (de)

2-1/2 Inch Inch Hub Diameter (dn)

3/4 Inch Inch approximate Pilot hole / bore +/- 1/16 inch (d1)

1-7/8 Inch Inch Total Width (A)
