160B-1 Sprockets With Split Taper Bushing
  1. 160B-1 Sprockets With Split Taper Bushing

160B-1 Sprockets With Split Taper Bushing

Product Item:HXST-116

Model:160B-1 Sprockets With Split Taper Bushing

Material: C45, stainless steel, etc.

Surface treatment:Teeth hardened, Black oxide, Zinc plated, Electrophoresis etc

Package:Standard export case, individual package (neutral or colorbox) available.

160B-1 Sprockets With Split Taper Bushing , split taper sprocket , sprocket taper lock bushing , sprocket with taper lock bushing
Send InquiryLive chat

Description

The "160B-1 Sprockets With Split Taper Bushing" refers to a specific type of sprocket that is designed to be used with a 160B Roller Chain and utilizes a split taper bushing system. Here is a breakdown of the components and their meanings:

160B: This indicates the specific chain size or pitch of the sprocket, in this case, a 160B roller chain.
1: The number 1 signifies that it is a single strand sprocket, meaning it has one row of teeth for engagement with the chain.
Split Taper Bushing: A split taper bushing is a type of bushing used for mounting sprockets onto a shaft. It features a split design with a tapered bore that can be easily mounted onto a shaft by tightening screws or bolts. The split taper bushing allows for easy installation and removal of the sprocket without the need for excessive disassembly.
