Specifications and model parameters of synchronous pulley

1、 Specification and model of Gage ladder type synchronous belt pulley

MXL type synchronous pulley, XL type synchronous pulley, L type synchronous pulley, H type synchronous pulley, XH type synchronous pulley, XXH type synchronous pulley

Parameter meaning of stepped tooth synchronous pulley

For example:

40-XL-037 AF indicates

Number of teeth: 40

Model: XL

Width code of timing belt used: 0.37 * 25.4=9.4mm

Wheel type code: AF (in addition, wheel types include AS, BS, BF, W)





2、 Specification and model of Gage West Germany T-tooth synchronous pulley

T2.5 type synchronous pulley, T5 type synchronous pulley, T10 type synchronous pulley, T20 type synchronous pulley, AT5 type synchronous pulley, AT10 type synchronous pulley, AT20 type synchronous pulley

Parameter Meaning of West German T-tooth Synchronous Belt Pulley

For example:

20 - T10 -25 W

Number of teeth: 20

Model: T10

Width code of timing belt used: 25mm

Wheel type code: W (in addition, wheel types include AS, BS, AF, BF)




3、 Specification and model of Gage circular arc tooth synchronous pulley

HTD 2M synchronous pulley, 3M synchronous pulley, 5M synchronous pulley, 8M synchronous pulley, 14M synchronous pulley, 20M synchronous pulley

STS/STPD S2M synchronous pulley, S3M synchronous pulley, S4.5 synchronous pulley, S5M synchronous pulley, S8M synchronous pulley, S14M synchronous pulley

RPP/HPPD RPP2M synchronous pulley, RPP3M synchronous pulley, RPP5M synchronous pulley, RPP8M synchronous pulley, RPP14M synchronous pulley

Parameter meaning of circular arc tooth synchronous pulley

For example:

1) 30-8M-30 AS

Number of teeth: 30

Model: 8M

Width code of timing belt used: 30mm

Wheel type code: AS (in addition, wheel types include BS, AF, BF, W)



2) 30-S8M-30 AS

Number of teeth: 30

Model: S8M

Width code of timing belt used: 30mm

Wheel type code: AS (in addition, wheel types include BS, AF, BF, W)



3) 30-RPP8M-30 AS

Number of teeth: 30

Model: RPP8M

Width code of timing belt used: 30mm

Wheel type code: AS (in addition, wheel types include BS, AF, BF, W)
