The importance of each link in an industrial conveyor chain

The acceleration device of the industrial Conveyor Chain realizes an accelerated process of the chain during the original chain transmission process, in order to facilitate the chain transfer process faster and more safely. In order to enable the automation of our chain conveyor line, It is necessary to add an acceleration device. The new chain structure and the safety stop on the acceleration device realize the storage and transportation on the conveyor line. At the same time, the full automation of the mechanized transportation process is realized, which reduces the labor intensity of workers.

The industrial conveying chain sending acceleration driving device is composed of a chain conveying driving device, an acceleration driving device, and a conveying chain assembly. It is characterized in that one end of the chain conveying driving device is connected to the conveying chain assembly through a driving sprocket, and the other end is connected to the conveying chain through a bracket. The chain frame is connected; one end of the acceleration driving device is connected to the eccentric guide wheel through a sleeve roller chain, and the other end is connected to the Transmission Chain frame through a shaft sleeve; one end of the transmission chain assembly is connected to the driving sprocket through a driving sprocket, and the other end is through a roller Contact with the workpiece. It reduces the speed of the entire line, accelerates the chain transportation only at the transition position, reduces the motor power of the system operation, and saves equipment investment.

 Daily maintenance of industrial conveyor chain:

1. Regularly check the lubrication of industrial conveyor chain equipment operation site, regular equipment refueling is required.

2, the equipment should always check that the bolts are loose, the motor must not exceed the rated current, and the bearing temperature rise exceeds the ambient temperature by 35 ° C, and the inspection should be stopped.

3, the industrial conveyor chain can start to run for 7-14 days, then it can be replaced every 3-6 months after changing the new oil.

4. Working in the use of conveyor chain equipment, about half of the time is recommended.

 When using a conveyor chain, how should we install an industrial conveyor chain? Let me tell you briefly:

First, we determine the centerline of the head and tail wheels.

Second, determine the horizontal planes of the head and tail wheels. (Note: In this place, the level is usually first searched through the embedded plate of the base) and then the slanting iron or gasket is used to ensure that the level of the head and tail wheels is within 1-2mm.

Again, ensure that the intermediate bracket is installed on a horizontal line. Before welding between the bracket and the embedded plate of the bracket (note: ensure horizontal and vertical), continuous welding is required, and then the track is installed. During the installation of the track, the track and head and tail sprocket must be ensured. Connection arc, so as to avoid the poor connection between the chain and the sprocket teeth.

Finally, the installation of the remaining chain plates and rollers is very simple. The main purpose is to just start the alignment. The horizontal and vertical determination must be as accurate as possible. If the deviation is too large, it must be found again.

Industrial conveyor chain is the main component of the chain plate conveyor and the backbone of the chain plate conveyor. It is a flexible piece where many of the same components are hinged. Like steel wire ropes and tapes, it can only transmit tension, and can transmit pressure only in special structures or under special circumstances in various directions. Industrial conveyor chain components are generally made of high-quality steel and engineering plastics-chain plates have many advantages, such as: adjacent links can flexibly rotate with each other, so there is no additional bending stress even when turning within a small radius; Each chain link has the possibility of good connection and fixing accessories; each chain link can be replaced and dry repaired, allowing some wear and corrosion of industrial conveyor chain parts; good heat and cold resistance, etc.
